TAE Power Supplies
Manufacturer: BeaconMedaes
Category: Controls

Documents & Manuals: View or Download

Equipment Description

BeaconMedaes TAE power supplies provide regulated 24 VDC power to TotalAlert Engineered (TAE) medical gas control systems. Multiple wattage ratings and supply voltage options are available from manufacturers including Lutze, Cutler Hammer, IDEC, and Phoenix Contact.

Technical Reference

Parts, service kits, and configuration data from the manufacturer's documentation.

Beacon P/NManuf.Output
Voltage		Watt
Rating		Amp
Rating		Model
Number		Part
Number		Supply
Voltage		Notes
4107 6527 22Lutze24 VDC36 W1.25 ADRA 30-24100-240 VAC
PWS01-001Cutler Hammer24 VDC55 W2.3 APSS55A115 VAC
PWS01-002IDEC24 VDC30 W1.3 APS5R-C24
PWS02-001Cutler Hammer24 VDC10 W0.4 APSS10E110-240 VAC
PWS02-002Cutler Hammer24 VDC10 W0.4 APSS10F380-480 VAC
PWS02-003Cutler Hammer24 VDC55 W2.3 APSS55B230 VACReplace with 4107 6506 90
PWS02-004Cutler Hammer24 VDC55 W2.3 APSS55C360-480 VAC
PWS02-005Cutler Hammer24 VDC25 W1 APSS25E110-240 VAC
PWS02-006Cutler Hammer24 VDC25 W1 APSS25F380-480 VAC
PWS02-007Phoenix24 VDC1 APS-100100-240 VAC
4107 6507 89Cutler Hammer24 VDC120 W5 APSG120E85-264 VAC
4107 6507 91Cutler Hammer24 VDC240 W10 APSG240E85-264 VAC
4107 6507 92Cutler Hammer24 VDC240 W10 APSG240F320-575 VAC
4107 6507 87Cutler Hammer24 VDC60 W2.5 APSG60E85-264 VAC
4107 6507 88Cutler Hammer24 VDC60 W2.5 APSG60F320-575 VACReplaced with 4107 6506 91
4107 6506 90Lutze24 VDC120 W5 ADRAN120-24A728-758115/230 VAC
4107 6506 91Lutze24 VDC120 W5 AWRA120-24722-803
4107 6533 90Phoenix Contact24 VDC1.75 A2868648
