DiamondCare Gas Outlets
Documents & Manuals: View or Download
Equipment Description
BeaconMedaes DiamondCare gas outlets are the current-generation medical gas outlet system offering Latch (Chemetron), DISS (CGA), Geometric (Puritan-Bennett), and Pin-Index (Diamond) keyed configurations. They are available in recessed wall, console, slide, surface-mount, and ceiling-drop variants with optional valve extension and upgrade kits.
Technical Reference
Parts, service kits, and configuration data from the manufacturer's documentation.
| Front Body Assemblies - Recessed Wall | ||||
| Latch Keyed (Chemetron) | DISS Keyed (CGA) | Geometric Keyed (PB) | Geometric Keyed (PB) 2016 | Pin Indexed Keyed (Diamond) |
| Front Body Assemblies - Console | ||||
| Latch Keyed (Chemetron) | DISS Keyed (CGA) | Geometric Keyed (PB) | Geometric Keyed (PB) | Pin Indexed Keyed (Diamond) |
| Front Body - Misc. | ||||
| Blank | Slide | Electrical | Electrical Ceiling Drop | |
| Valve Extension Kit | Surface Mount Kit | Upgrade Kits | ||
| Rough-In Assemblies | ||||
| Recessed Wall | Console- Piped | Console - DISS | Slide | |
