Western Dual Line Regulator Assemblies
Documents & Manuals: View or Download
Equipment Description
Western Enterprises dual line regulator assemblies provide pressure regulation for medical gas pipeline systems. Available in 1/4″ and 1/2″ piping configurations for 50 psig service, they include dual line regulators, ball valves, pressure gauges, and relief valves.
Technical Reference
Parts, service kits, and configuration data from the manufacturer's documentation.
| Item | Part Number | Description | Item | Part Number | Description |
| n/a | 107070-20 | Dual Line Regulator Assembly, 1/4" Piping, 50 psig | n/a | 290582-97 | Dual Line Regulator Assembly, 1/2" Piping, 50 psig |
| n/a | 106070-22 | Dual Line Regulator Assembly, 1/4" Piping, N2 | n/a | 6-DLA-5 | Dual Line Regulator Assembly, 1/2" Piping, N2 |
| 1 | 290582-10 | Adapter, Outlet Bushing | 1 | WMV-8-75 | Relief Valve, 75 psig |
| 2 | 290555-00 | 0-100 psig Gauge | 2 | 690582-73 | Line Regulator, 1/2", 50 - 125 psig |
| 3 | 290552-00 | Ball Valve | 6-WEWMR-2-5 | Line Regulator, 1/2", N2 | |
| 4 | 290582-34 | Nipple, Inlet CGA-024 x 1/4" MPT | 290510-00 | Repair Kit for REGO 1684Y Regulator | |
| 5 | 290582-33 | Nut, CGA-024 (7/8-14 UNF-2B RH) | 3 | G-2-200W | Gauge |
| 6 | 6-WEWMR-1-15 | Line Regulator | 4 | WMV-5-8 | Ball Valve |
| 6-WMR-1-20 | Line Regulator, N2 | ||||
| 7 | 290582-02 | Pipe Away Adapter | |||
| 8 | 290582-01 | Relief Valve, 75 psig | |||
| 290556-00 | Relief Valve, 250 psig |
